Rated for 3.0 MPa (30 bar) and built with 3mm-thick 304 stainless steel, it delivers reliable performance and long service life in demanding high-pressure pneumatic systems.
10L high-pressure stainless steel air tank designed for demanding industrial applications. Constructed from thickened 304 stainless steel, it supports working pressures up to 3.0 MPa (30 bar) and features a compact, vertically oriented design with multiple ports for flexible system integration.
Rated for 3.0 MPa (30 bar) and built with 3mm-thick 304 stainless steel, it delivers reliable performance and long service life in demanding high-pressure pneumatic systems.
Made of 304 stainless steel with a polished finish, the tank resists rust and corrosion, ensuring clean air storage and low maintenance in humid or harsh environments.
Its vertical layout and provided mounting holes (340×80 mm pattern) enable secure, space-efficient installation in equipment racks or confined industrial settings.
Equipped with multiple G½″ and G¼″ ports, it supports easy integration of valves, gauges, and piping. The product also supports custom modifications to meet specific application requirements.
| P/N | Pressure (bar) | L*D*H(mm) | Thickness(mm) | Package Size(mm) | Net Weight(KG) | Gross Weight(KG) | Ports |
| 5L high pressure | 50 | 290*159*249 | 5 | 300*180*260 | 6.6 | 7.6 | 3:G1/4, 2:G1/2 |
| 10L high pressure | 50 | 544*159*221 | 5 | 568*250*180 | 9.7 | 11 | 4:G1/2, 1:G1/4 |
| 20L high pressure | 50 | 626*289*219 | 5 | 650*230*300 | 21.7 | 24 | 4:G1/2, 1:G1/4 |
| 5L high pressure | 30 | 290*159*249 | 3 | 320*180*260 | 4.8 | 5.5 | 2: G1/2, 3:G1/4 |
| 10L high pressure | 30 | 530*159*249 | 3 | 570*170*280 | 8.1 | 10 | 2: G1/2, 3:G1/4 |
| 20L high pressure | 30 | 626*219*289 | 5 | 660*260*310 | 14.7 | 15.2 | 4: G1/2, 1:G1/4 |
